8 wire, 1.8 degree, 2 phase, 4.2 Amp
Single 1/2" - KEYED-SHAFT (0.2" key)
Single 1/2" - KEYED-SHAFT (0.2" key)
650 oz-in, 86HS78-4208-05, Nema 34
8 wire, 1.8 degree, 2 phase, 4.2 Amp
Single 1/2" D-shaft
Single 1/2" D-shaft
1200 oz-in, 86HS115-4208-05, Nema 34
Price $100.00
Price $145.00
8 wire, 1.8 degree, 2 phase, 4.2 Amp
Single 14mm D-shaft
Single 14mm D-shaft
1700 oz-in, 86HS155-4208, Nema 34
Out of stock
www.StepperMotorCanada.ca is owned and operated by Pro Power Electric. Copyright (C) 2019. All rights reserved.
No material may be reproduced in part or in whole without written consent from holders.
No material may be reproduced in part or in whole without written consent from holders.
|
Nema34
Model No.
|
Step
Angle
Degrees
|
Motor
Length
mm
|
Current
/phase
Amps
|
Resistance
/phase
ohms
|
Inductance
/phase
mH
|
Holding
Torque
N.m
|
# of
leads
|
Detent
Torque
Kg.cm
|
Rotor
Inertia
g.cm
|
Mass
Kg
|
Holding
Torque
Oz-In
|
|---|---|---|---|---|---|---|---|---|---|---|---|
|
86HS68-
5904
|
1.8 | 67 | 5.9 | 0.28 | 1.7 | 3.4 | 4 | 0.8 | 1000 | 1.7 | 481 |
|
86HS68-
2808
|
1.8 | 67 | 2.8 | 1.4 | 3.9 | 3.4 | 8 | 0.8 | 1000 | 1.7 | 481 |
|
86HS78-
5504
|
1.8 | 78 | 5.5 | 0.46 | 4.0 | 4.6 | 4 | 1.2 | 1400 | 2.3 | 651 |
|
86HS78-
4208
|
1.8 | 78 | 4.2 | 0.75 | 3.4 | 4.6 | 8 | 1.2 | 1400 | 2.3 | 651 |
|
86HS97-
4504
|
1.8 | 97 | 4.5 | 0.66 | 3.0 | 5.8 | 4 | 1.7 | 2100 | 3.0 | 821 |
|
86HS97-
4008
|
1.8 | 97 | 4.0 | 0.98 | 4.1 | 4.7 | 8 | 1.7 | 2100 | 3.0 | 665 |
|
86HS100-
6004
|
1.8 | 100 | 6.0 | 0.36 | 2.8 | 7.0 | 4 | 1.9 | 2200 | 3.1 | 991 |
|
86HS115-
6004
|
1.8 | 115 | 6.0 | 0.6 | 6.5 | 8.7 | 4 | 2.4 | 2700 | 3.8 | 1232 |
|
86HS115-
4208
|
1.8 | 115 | 4.2 | 0.9 | 6.0 | 8.7 | 8 | 2.4 | 2700 | 3.8 | 1232 |
|
86HS126-
6004
|
1.8 | 126 | 6.0 | 0.58 | 6.5 | 6.3 | 4 | 2.9 | 3200 | 4.5 | 894 |
|
86HS155-
6004
|
1.8 | 155 | 6.0 | 0.68 | 9.0 | 13.0 | 4 | 3.6 | 4000 | 5.4 | 1841 |
|
86HS155-
4208
|
1.8 | 155 | 4.2 | 1.25 | 8.0 | 12.2 | 8 | 3.6 | 4000 | 5.4 | 1727 |
|
|
|||||||||||
Step Angle ----------------------- 1.8° ± 5%
Temperature Rise ------------- 80° Max
Ambient Temperature -------- -20° ~+50°
Insulation Resistance--------- 100 MO Min., 500VDC
Dielectric Strength: ------------ 820VAC for 1S 3mA
Shaft Radial Play --------------- 0.02Max. (450g-load)
Shaft Axial Play ------------------ 0.08Max. (450g-load)
Max. Radial force---------------- 220N (20mm from the flange)
Max. Axial force------------------- 60N
Temperature Rise ------------- 80° Max
Ambient Temperature -------- -20° ~+50°
Insulation Resistance--------- 100 MO Min., 500VDC
Dielectric Strength: ------------ 820VAC for 1S 3mA
Shaft Radial Play --------------- 0.02Max. (450g-load)
Shaft Axial Play ------------------ 0.08Max. (450g-load)
Max. Radial force---------------- 220N (20mm from the flange)
Max. Axial force------------------- 60N
General Specification:
Electrical specification:
3, 4, 5, 8, 10, 12, 15, 16, 20, 25, 32, 40,
Geared Stepper Motors, Nema 34
Price $ Call
Digital stepper motor driver, 32-bit DSP.
60Vac, 2.0 - 6.0 Amp, 2 Phase, AC / DC input.
Over voltage, over current, short circuit protection.
Automatic idle-current reduction.
60Vac, 2.0 - 6.0 Amp, 2 Phase, AC / DC input.
Over voltage, over current, short circuit protection.
Automatic idle-current reduction.
Nema 34 Digital D2060AC Micro Driver
Price $120.00
Full List of NEMA 34 Stepper Motors
8 wire stepper motors are the same as 4 wire stepper motors. The only difference is that a 4 wire stepper motor have lead connections made inside the motor with no option to select parallel or series wiring. You get, what you get.
With 8 wire motors you can wire to your preference, series or parallel and even unipolar. Connections are very easy to do. Just down load the wiring chart and make the connections as required.
With 8 wire motors you can wire to your preference, series or parallel and even unipolar. Connections are very easy to do. Just down load the wiring chart and make the connections as required.
Why do we sell 8 wire stepper motors?
8 wire, 1.8 degree, 2 phase, 2.8 Amp
Single 1/2" D-shaft
Single 1/2" D-shaft
481 oz-in, 86HS68-2808-11F, Nema 34
Price $90.00
The 2DM860H is the latest digital stepper motor driver which adopts 32-bit DSP control technology and built-in microstepping technology.
80Vac, 2.0 - 6.0 Amp, 2 Phase.
80Vac, 2.0 - 6.0 Amp, 2 Phase.
Nema 34 Digital Stepper Driver 2DM860H
Price $130.00
8 wire, 1.8 degree, 2 phase, 4.0 Amp
Single 1/2" D-shaft
Single 1/2" D-shaft
963 oz-in, 86HS97-4008-01F, Nema 34
Price $120.00
Most stepper motors can be ordered in Dual shaft, D shaft, and Keyed shaft.
Standard and metric sizes.
Standard and metric sizes.
Dual Shaft Stepper Motors, Nema 34
Price $ Call
Add this cap to the back of your nema34 motor to neaten wiring connections.
Add on an aviator plug for quick connections.
Add on an aviator plug for quick connections.
Nema 34 End Cap
Price $15.00
Available gear ratios 1:
64, 100, 120, 125, 160, 200, 256,
320, 512, 1000
20 mm keyed shaft
Nema 34
